Climatology Lab TerraClimate

Kyle Messier, with assistance from GitHub Copilot

2026-05-20

This article demonstrates a compact workflow for Climatology Lab TerraClimate data.

This vignette runs its live workflow when rendered locally. The heavy download, processing, extraction, and plotting chunks are skipped automatically on CI, CRAN checks, and pkgdown builds; set AMADEUS_RUN_VIGNETTES=true to force live execution in those environments.

Available inputs and data availability

download_data(dataset_name = "terraclimate", ...) accepts either the full variable names below or their TerraClimate codes.

Code	Variable
aet	Actual Evapotranspiration
def	Climate Water Deficit
pet	Potential evapotranspiration
ppt	Precipitation
q	Runoff
soil	Soil Moisture
srad	Downward surface shortwave radiation
swe	Snow water equivalent - at end of month
tmax	Max Temperature
tmin	Min Temperature
vap	Vapor pressure
ws	Wind speed
vpd	Vapor Pressure Deficit
PDSI	Palmer Drought Severity Index

• Temporal resolution: monthly; each download is an annual NetCDF file containing monthly layers for one variable.
• Year input: use a single year or a start/end pair such as c(2018, 2022).
• Availability check: the wrapper validates the first requested variable-year URL and stops if that request returns HTTP 404.
• Major constraint: TerraClimate downloads do not require authentication.

Download representative requests

directory_to_save <- file.path(tempdir(), "terraclimate_workflow")
download_data(
  dataset_name = "terraclimate",
  variables = c("Precipitation"),
  year = 2019,
  directory_to_save = directory_to_save,
  acknowledgement = TRUE
)

Process one workflow-ready data product

processed_data <- process_covariates(
  covariate = "terraclimate",
  variable = "ppt",
  date = c("2019-01-01", "2019-02-01"),
  path = dirname(list.files(
    directory_to_save,
    pattern = "\\.nc$",
    recursive = TRUE,
    full.names = TRUE
  )[1]),
  extent = terra::ext(-114.9, -102.0, 31.3, 41.1)
)

terra::plot(processed_data, main = "TerraClimate ppt for Jan-Feb 2019")

Calculate covariates at points

domain_x <- c(terra::xmin(processed_data), terra::xmax(processed_data))
domain_y <- c(terra::ymin(processed_data), terra::ymax(processed_data))
domain_dx <- diff(domain_x)
domain_dy <- diff(domain_y)

candidate_xy <- expand.grid(
  lon = seq(domain_x[1] + 0.12 * domain_dx, domain_x[2] - 0.12 * domain_dx, length.out = 5),
  lat = seq(domain_y[1] + 0.12 * domain_dy, domain_y[2] - 0.12 * domain_dy, length.out = 5)
)
example_points_sf <- sf::st_as_sf(
  candidate_xy,
  coords = c("lon", "lat"),
  crs = 4326
)
example_points_sf$site_id <- paste0("site_", seq_len(nrow(example_points_sf)))


point_values <- calculate_covariates(
  covariate = "terraclimate",
  from = processed_data,
  locs = example_points_sf,
  locs_id = "site_id",
  radius = 0,
  fun = "mean",
  geom = "sf"
)

print(point_values)

Workflow for an annual average covariate

annual_process <- process_covariates(
  covariate = "terraclimate",
  variable = "ppt",
  date = c("2019-01-01", "2019-12-31"),
  path = dirname(list.files(
    directory_to_save,
    pattern = "\\.nc$",
    recursive = TRUE,
    full.names = TRUE
  )[1]),
  extent = terra::ext(-114.9, -102.0, 31.3, 41.1)
)

point_year <- calculate_covariates(
  covariate = "terraclimate",
  from = annual_process,
  locs = example_points_sf,
  locs_id = "site_id",
  radius = 0,
  .by_time = "year",
  fun = "mean",
  geom = "sf"
)

print(point_year)
